High Torque Low Speed Hydraulic Motor 100 - 200 R/Min For Mining Machinery

Brand Name : Helm Tower Hydraulic

Model Number : MS02 MSE02

Certification : ISO9001

Place of Origin : CHINA

MOQ : 1

Payment Terms : L/C, T/T

Supply Ability : 1000 sets per month

Delivery Time : 15 working days

Packaging Details : wooden case

Certificate : ISO9001:2008

Warranty : 1 Year

Type : Low Speed High Torque Hydraulic Motor

Color : Follow customer's requirement

Application : Mining Machinery

Displacement : 172-398 ml/r

Rated speed : 100-200 r/min

Rated torque : 683-1583

Contact Now

Low Speed High Torque Hydraulic Motor MS02 MSE02 100-200 r/min for Mining Machinery

Modular design, High efficiency, High pressure and smooth running even at very low speeds,

Permissible Radial and Axial load, Motor with multi-disc brake, Motor emission control,

Application: As revolution mechanism of hydraulic system, used for forklift, skid steer loader, grab, metallurgy mine equipment, shipping port equipment, hydraulic winch, etc.

Type

Displacement

 MS02-8 MS02-9 MS02-0 MS02-1 MS02-2
Full/Semi Full/Semi Full/Semi Full/Semi Full/Semi
Displacement(ml/r) 172 86 213 106 235 118 255 128
Max power(kw) 16 10 16 10 16 10 16 10

Pressure discrepancy 10MPa Torque

(N.m)

 273 136 340 170 351 175 405 202
Rated torque(N.m) 643 796 878 953
Rated pressure(MPa) 25 25 25 25
Max pressure(MPa) 40 40 40 35
Rated speed(r/min) 140 140 140 120
Speed range(r/min) 0-310 0-310 0-310

0-260

HMS MOTOR APPLIATION

Our MS MSE series hydraulic motor are widely applied to agriculture machine, construction machine, coal mine machine, marine equipment, forestry machine etc.

Construction: road building and maintenance, earth moving, finishing, drilling, trenching, recycling, mining and boring machines.

Minging: mini road header, scraper, heavy duty handling car coal mine drill.

Agriculture: combine and others specialty harvesters, sprayers, forestry equipment,

Handling: forklift trucks, aerial work platforms, conveyors, aircraft loading equipment,

Industry: process, paper, foundry, food.

Marines: fishing, harbor,

Transportation: material, heavy duty, on-highway.

For instance:
- BELL 220A Telelogger
- HAMM 4011 Road Roller
- BOMAG 211 Soil compactor
- BOMAG 130 AD Road Roller
- BOMAG Roller BW213 D2
- Carterpillar 226B,
- Carterpillar CS-563 compactor
- John Deere 280 skid steer,
- BOBCAT T190 skid steer and excavators
- VERMEER Horizontal Directional Drill
- SANDVIK Machine
- Gehl 6635 Skid steer
- Greenbeans and pea Harvesting Machine(PMC-979-AT

High Torque Low Speed Hydraulic Motor 100 - 200 R/Min For Mining Machinery

High Torque Low Speed Hydraulic Motor 100 - 200 R/Min For Mining Machinery
